FastGRAB™ / Concrete Step Handles TSZ
From $2,488.00each
Member: $$2,313.84 / each
| Weight | N/A |
|---|---|
| Type |
TSZ-UNI ,TSZ-MAXI |
| Brand |
Description
Suitable for handling steps, kerb stones etc. in conjunction with a lifting device.
Further information
- Easily adjustable opening width by means of a spring-loaded bolt.
- Considerable inside height. Conical kerb stones are also gripped securely, as the gripper has an inside height of 185 mm thus being able to grip underneath the conical form.
- Lifting eye for attaching to crane hook.
- Automatic release for fully automatic switch-over from “full” to “empty”.
- Exchangeable profiled rubber seals.
- Galvanised finish.
Technical details
| Type | Order no. | Working Load Limit/WLL (lbs) | Dead Weight (lbs) | Gripping Range (in) | Length of Gripper (in) | Inside Height (in) |
|---|---|---|---|---|---|---|
| TSZ-UNI | 53100338-003 | 1323 | 64 | 1,97-23,62 | 13,78 | 7,28 |
| TSZ MAXI | 53100364-003 | 1323 | 77 | 33,46-43,31 | 13,78 | 7,28 |
