Oaks Nueva®150 Wall

Enrich your contemporary-styled landscape design with the clean lines and well-coordinated colour palette of the Nueva® 150 Wall. Designed with the versatility and strength required to help increase usable space, the Nueva® 150 Wall system manages troublesome grade changes with elegance and durability. Our patented M-Lock technology and hollow cores allow for the use of stabilized backfill, creating ultimate stability in the most challenging applications.

Recommended Use: Commercial, Garden Wall, Residential, Retaining Wall

FINISH: SMOOTH

MATERIAL: CONCRETE

	Bundle Specifications					Per Section Specifications
BUNDLES	Layers	Area sq.ft.	Lin.Ft.	Pieces	Weight lbs	SECTIONS	Area sq.ft.	Lin.Ft.	Pieces	Weight lbs
Combo Bundle 16″ Unit 20″ Unit 20″ Corner/End Unit 24″ Unit	4	26	52.5	8 8 8 8	3200	Layer	6.5	13.1	2 2 2 2	800

Sizes

16″ Unit

Width 400 mm (15.75″)
Height 150 mm (5.91″)
Depth 300 mm (11.81″)

20″ Unit

Width 500 mm (19.69″)
Height 150 mm (5.91″)
Depth 300 mm (11.81″)

20″ Corner/End Unit

Width 500 mm (19.69″)
Height 150 mm (5.91″)
Depth 300 mm (11.81″)

24″ Unit

Width 600 mm (23.62″)
Height 150 mm (5.91″)
Depth 300 mm (11.81″)
